Description
The D-Link DPE-301GI is a wired PoE injector designed to provide power and data connectivity to compatible devices via a single Ethernet cable, simplifying network installation and maintenance. This device offers a data + P port with half/full duplex support and is compatible with IEEE 802.3, 802.3u, 802.3at, 802.3af, and 802.3ab standards , ensuring compatibility with most modern equipment requiring Ethernet power, such as IP cameras, access points, or VoIP phones. The 10/100/1000BASE-T port allows Gigabit speeds, ensuring efficient and stable data transfer. Additionally, the injector features a data input port that also supports half/full duplex operation and Gigabit Ethernet connections, guaranteeing signal integrity and speed for powered devices. It has blue and green LED indicators that show power status and active link, facilitating quick monitoring of operation. The physical design features compact dimensions of 109.8 x 62.2 x 24.5 mm and a light weight of 65 grams , with a white finish that integrates discreetly into professional environments. It is powered by a 55V, 0.6A power adapter, with a maximum consumption of 32.4 watts and an output of 0.6A at 55V , suitable for powering devices with high power demands. This injector operates in a temperature range of -10 to 50°C and supports operating humidity between 5% and 95% without condensation , offering resistance for various environments. It has internationally recognized certifications such as CE, FCC, VCCI, RCM, RoHS, and BSMI , guaranteeing regulatory compliance and industrial quality. Its nominal power supply is 240V with a frequency of 50-60Hz , adapting to common electrical standards. In summary, the D-Link DPE-301GI is a robust and compatible solution for installations that require simultaneously injecting power and data via PoE, optimizing network infrastructure with advanced technology and technical reliability.
- Plug-in product: Yes
- Plug type: EU plug
- Connections:
- Ethernet LAN
- 2
- RJ45
- Power supply:
- electrical grid
- CC
- Color: White
- Speed:
- 1000 Mbit/s
- 10 Gbit/s
- 10/100/1000 Mbps
- Voltage:
- 100-240V
- 240 V
- 100 - 240 V
- Frequency:
- 50-60 Hz
- 50 - 60 Hz
- Certified: FCC
- Features: LED operation indicator
- Amperage: 0.6 A
D-Link DPE-301GI. Ethernet interface type: Fast Ethernet, Gigabit Ethernet, Ethernet LAN data transfer rate: 10, 100, 1000 Mbit/s, Communication standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u. Product color: White, Certification: CE, FCC, VCCI, RCM. Output power: 32.4 W, AC adapter input voltage: 100 - 240 V, AC adapter frequency: 50/60 Hz. Product weight: 70 g, Product dimensions (LxWxH): 109.8 x 62.2 x 24.5 mm. Package length: 153 mm, Package width: 213 mm, Package height: 68 mm
- Ethernet interface type: Fast Ethernet, Gigabit Ethernet
- Ethernet LAN data transfer rate: 10, 100, 1000 Mbit/s
- Power over Ethernet (PoE): Yes
- Communication Standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
- Shelf assembly: No
- Product color: White
- LED indicators: Yes
- Certifications: CE, FCC, VCCI, RCM
- Number of Ethernet LAN (RJ-45) ports: 2
- DC-in port: Yes
- Output power: 32.4 W
- AC adapter input voltage: 100 - 240 V
- AC adapter frequency: 50/60 Hz
- Output current: 0.6 A
- Operating temperature: 0 - 50 °C
- Maximum operating temperature: 32 - 122 °F
- Operating relative humidity range: 5 - 95%
- Temperature range (storage): -30 - 70 °C
- Non-functioning humidity: 5 - 95%
- Product weight: 70 g
- Product dimensions (LxWxH): 109.8 x 62.2 x 24.5 mm
- Package length: 153 mm
- Package width: 213 mm
- Package height: 68 mm
- Package weight: 398 g
- Number of products included: 1 unit(s)
- Shipping package length: 32.6 cm
- Shipping package width: 23.3 cm
- Shipping package height: 36 cm
- Net weight of shipping box: 4.1 kg
- Quantity per shipping package: 10 unit(s)
- Gross weight of the pallet (air): 297.8 kg
- Number of boxes per pallet (air): 60 unit(s)
- Quantity per pallet (air): 600 unit(s)
- Pallet length: 120 cm
- Pallet width: 110 cm
- Pallet height (air): 194 cm
- Gross weight of the pallet (sea): 297.8 kg
- Number of boxes per pallet (mar): 60 unit(s)
- Quantity per pallet (mar): 600 unit(s)
- Pallet height (sea): 194 cm
- Shipping package weight: 4.63 kg
