Description
The ZyXEL GS1350-12HP-EU0101F is an advanced managed switch designed for professional environments that demand efficiency, security, and flexibility in network connectivity. This model stands out for offering 10 Gigabit Ethernet RJ45 ports (10/100/1000) , providing fast and stable data transmission, as well as supporting PoE (Power over Ethernet), allowing you to power devices such as IP cameras, wireless access points, or VoIP phones directly via the network cable. With a switching capacity of 24 Gbit/s and a MAC address table for 8000 entries, this switch manages large volumes of traffic without performance loss, adapting perfectly to video surveillance infrastructures, offices, or small and medium-sized businesses. Its power consumption of 160.3 W demonstrates its ability to support multiple PoE devices simultaneously, ensuring operational efficiency and centralized management. Compatible with network standards such as IEEE 802.1Q, 802.1pe, 802.3ad, among others, it ensures interoperability and advanced Layer 2 configuration. Its robust gray design and rack-mount format facilitate integration into racks or data centers, optimizing space and cable organization. Copper materials and AC cable inclusion ensure simple installation and reliable connectivity. This multifunctional switch offers functionality and versatility, making it a solid solution for networks that require PoE, efficient management, and advanced configuration options. Combining professional features and ease of integration, the ZyXEL GS1350-12HP-EU0101F is a reliable solution for infrastructures that demand network performance and security.
- Ports:
- 10 x 100/1000 Mbps x 10
- SFP x 2
- 8
- 10
- AC Input: 100 - 240 V
- Frequency:
- 50/60 Hz
- 50-60 Hz
- Power consumption: 160.3 W
- PoE ports:
- 8
- 130 W
- Throughput: 24 Gbps
- Forwarding Rate: 17.8 Mbps
- Buffer: 525K bytes
- Approximate dimensions: 26.7 x 16.2 x 4.4 cm
- Operating temperature range: -20ºC / 50ºC
- Operating humidity range: 5% - 95%
- Connections:
- RJ45
- 8
- Ethernet LAN
- Plug-in product: Yes
- Plug type: EU plug
- Color: Gray
- Type: Switch
- Power supply:
- electrical grid
- AC cable
- Voltage:
- 100-240 V
- 100 - 240 V
- Material: Copper
- Support: Multi-support
- Number of slots: 2
- Features: LED operation indicator
- Amperage: 1 A
- Power: 130 W
- Weight: 1.63 kg
- Approximate temperature: -40º / 70º
- Security: IGMP
Zyxel GS1350-12HP-EU0101F. Switch type: Managed, Switch layer: L2. Ethernet port types: RJ-45 Basic Switching: Gigabit Ethernet (10/100/1000), Number of RJ-45 Basic Switching Ethernet ports: 10. MAC address table: 8000 entries, Routing/switching capacity: 24 Gbit/s. Communication standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ad, IEEE... Power over Ethernet (PoE). Rack mount.
- Switch type: Managed
- Switch layer: L2
- Web-based management: Yes
- Location Settings (DFL) configuration: Yes
- System event report: Yes
- MIB support: RFC 1066, RFC 1213, 1157, RFC 1493, RFC 1643, RFC 1757, RFC 2011, 2012, 2013, RFC 2233, RFC 2358, RFC 2674, RFC 2819, 2925, RFC 3621, RFC 4293, RFC 4292, RFC 4022, RFC 4113
- Number of Basic Switching RJ-45 Ethernet ports: 10
- Basic switching RJ-45 Ethernet port types: Gigabit Ethernet (10/100/1000)
- Number of SFP module slots: 2
- Communications Standards: IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
- 10G support: No
- Copper Ethernet wiring technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Door mirroring: Yes
- Flow control support: Yes
- Diffusion storm control: Yes
- Spanning tree protocol: Yes
- VLAN support: Yes
- Virtual LAN features: MAC address-based VLAN,Port-based VLAN
- Number of VLANs: 256
- Fiber ethernet cabling technology: 1000BASE-X
- MAC address table: 8000 entries
- Routing/switching capacity: 24 Gbit/s
- Routing rate: 17.8 Mpps
- Stored packet memory: 0.525 MB
- DHCP features: DHCP client, DHCP relay, DHCP snooping
- IGMP snooping: Yes
- IGMP Proxy: Yes
- Encryption/Security: SNMP, SNMPv3, SSH, SSL/TLS
- MAC address filtering: Yes
- Loop protection: Yes
- Queue scheduling algorithm: SPQ, WFQ, Weighted Round Robin (WRR)
- Multicast support: Yes
- Shelf assembly: Yes
- Product color: Gray
- LED indicators: Yes
- Noise level: 27.3 dB
- Firmware upgradable: Yes
- MTBF: 1065025.45 h
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Power consumption (max): 160.3 W
- Power over Ethernet (PoE): Yes
- Number of PoE ports: 8
- Total Power over Ethernet (PoE) Budget: 130 W
- Operating temperature: -20 - 50 °C
- Temperature range (storage): -40 - 70 °C
- Operating relative humidity range: 5 - 95%
- Non-functioning humidity: 5 - 95%
- Heat dissipation: 546.62 BTU/h
- Width: 267 mm
- Depth: 162 mm
- Height: 44 mm
- Product weight: 1.63 kg
- Cables: AC
- Shelf mounting kit: Yes
