Description
The ZyXEL RGS200-12P is a professional-grade managed switch designed to offer robust and flexible connectivity in demanding environments such as industrial infrastructure or video surveillance systems. This Layer 2 switch features 8 RJ-45 Gigabit Ethernet (10/100/1000) ports , enabling efficient transmission of large data volumes with 24 Gbit/s switching capacity and full duplex support. It integrates advanced features such as Power over Ethernet (PoE) , facilitating the powering of compatible devices via the network cable, simplifying installation and reducing the need for additional power outlets. Its black metal housing and support for wall or rack mounting ( multi-support ) offer versatility and durability, adapting to both technical rooms and industrial environments. It supports essential network standards such as IEEE 802.1Q, IEEE 802.1D and others, ensuring compatibility with a wide variety of equipment and network topologies. The MAC address table with up to 8000 entries ensures efficient traffic management, while its wide DC input voltage range (12 - 58 V) provides flexibility for different power supplies. The ZyXEL RGS200-12P is a reliable and adaptable solution for those seeking a high-performance managed switch that is easy to integrate into critical networks.
- Connections:
- RJ45
- 8
- Ethernet LAN
- rj45 x 8
- Plug-in product: Yes
- Plug type: EU plug
- Type: Switch
- Power Source: mains electricity
- Color: Black
- Material: Metal
- Features:
- Wall mount
- Plug and play
- Support: Multi-support
- Number of slots: 4
- IP Rating: IP30
- Power: 240 W
- Security: IGMP
Zyxel RGS200-12P. Switch type: Managed, Switch layer: L2. Ethernet port types: RJ-45 Basic Switching: Gigabit Ethernet (10/100/1000), Number of RJ-45 Basic Switching Ethernet ports: 8. Full duplex. MAC address table: 8000 entries, Routing/switching capacity: 24 Gbit/s. Communication standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE... DC input voltage: 12 - 58 V. Power over Ethernet (PoE). Wall mountable, Rack mountable
- Switch type: Managed
- Switch layer: L2
- Support for Quality of Service (QoS): Yes
- Web-based management: Yes
- ARP Inspection: Yes
- System event report: Yes
- MIB support: RFC 2233 IF MIB, RFC1213 MIB II, RFC 1757 RMON 1/2/3/9, RFC1215, RFC1493, RFC 2674, LLDP-EXT-MED MIB
- Number of Basic Switching RJ-45 Ethernet ports: 8
- Basic switching RJ-45 Ethernet port types: Gigabit Ethernet (10/100/1000)
- Number of SFP module slots: 4
- Fiber Optic Connector: SFP
- Communications Standards: IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
- 10G support: No
- Copper Ethernet wiring technology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Door mirroring: Yes
- Full duplex: Yes
- Flow control support: Yes
- Link aggregation: Yes
- Diffusion storm control: Yes
- Limitation rate: Yes
- Automated trading: Yes
- VLAN support: Yes
- Virtual LAN Features: Tagged VLAN
- Number of VLANs: 1024
- Fiber ethernet cabling technology: 1000BASE-X
- Transmission distance (max): 40 km
- MAC address table: 8000 entries
- Routing/switching capacity: 24 Gbit/s
- Productivity: 17.86 Mpps
- Store-and-forward: Yes
- Number of rows: 8
- Supports jumbo packages: Yes
- Jumbo packs: 9000
- Packet memory stored: 0.5 MB
- Access control list (ACL): Yes
- IGMP snooping: Yes
- Encryption/Security: 802.1x RADIUS, HTTPS, SNMP, SSH-2
- MAC address filtering: Yes
- SSH/SSL support: Yes
- Authentication: Guest VLAN, MAC-based authentication (Message Authentication Code), Port-based authentication
- Multicast support: Yes
- Shelf assembly: Yes
- Product color: Black
- Product body material: Metal
- International Protection Code (IP): IP30
- Wall mountable: Yes
- DIN rail mounting: Yes
- Firmware upgradable: Yes
- Buffer size: 512 KB
- Plug and Play: Yes
- MTBF: 568,430 h
- DC input voltage: 12 - 58 V
- Power consumption (max): 255 W
- Power over Ethernet (PoE): Yes
- Number of Power over Ethernet plus (PoE+) ports: 8
- Total Power over Ethernet (PoE) Budget: 240 W
- Operating temperature (TT): -40 - 75 °C
- Temperature range (storage): -40 - 85 °C
- Operating relative humidity (HH): 5 - 95%
- Non-operating humidity: 5 - 90%
- Heat dissipation: 86955 BTU/h
- Width: 77 mm
- Depth: 127.3 mm
- Height: 154 mm
- Weight: 1.45 kg
- Wall mounting kit: Yes
- Shelf mounting kit: Yes
- Package length: 133 mm
- Packaging depth: 192 mm
- Package height: 238 mm
- Package weight: 1.9 kg
- Input voltage: 12 - 58 V
